DirectX 12 Demo

In the following sections, we will create the DirectX 12 demo application. In this tutorial, the demo will only create a window and clear the screen. Rendering of geometry will be handled in a later tutorial.

The following steps will be shown:

• Register the window class
• Create the window
• Query the GPU adapters
• Create a DirectX 12 device
• Create a command queue
• Create a swap chain
• Create command allocator & command list
• Handle GPU synchronization
• Update & Render
• Handle resizing
• Handle full-screen toggling

Preamble

The preamble of the source includes the header files that are required to create the demo. Any variables that are used for the demo are also declared in the preamble.

First, the required Windows header files are declared.

Since this demo uses the Windows library functions, the ubiquitous Windows.h header file is included on line 2. In order to minimize the number of header files that are included in the Windows.h header, the WIN32_LEAN_AND_MEAN macro is defined just before the Windows.h include.

The shellapi.h header file included on line 3 contains the definition for the CommandLineToArgvW function. This function will be used later to parse the command-line arguments passed to the application.

The min and max macros defined in the standard C library header file may conflict with the std::min and std::max functions defined in the algorithm STL header. To avoid any compiler errors, the min and max macros should be undefined and only the std::min and std::max functions should be used.

In the Windows.h header file, a macro called CreateWindow is defined. Since a function with the same name is defined in this source file, the CreateWindow macro is undefined on line 18. The CreateWindow macro is not needed in this source file since the CreateWindowExW function is used instead to create the OS window.

The wrl.h header file included on line 22 contains the definition of the ComPtr template class. The ComPtr template class provides smart pointer functionality for COM objects. Please refer to COM Coding Practices for more information on proper use of COM pointers. Since all DirectX 12 objects are COM objects, the ComPtr template class is used to track the COM object lifetimes.

In the next section, the DirectX 12 specific header files are included.

The Direct3D 12 header file is included on line 26. This header file contains all of the Direct3D 12 objects (Device, CommandQueue, CommandList, etc…).

The Microsoft DirectX Graphics Infrastructure (DXGI) is used to manage the low-level tasks such as enumerating GPU adapters, presenting the rendered image to the screen, and handling full-screen transitions, that are not necessarily part of the DirectX rendering API. DXGI 1.6 adds functionality in order to detect HDR displays. HDR rendering will be discussed in another article.

The d3dcompile.h header file contains functions to compile HLSL code at runtime. It is recommended to compile HLSL shaders at compile time (when the application is compiled into an executable) but for demonstration purposes, it might be more convenient to allow runtime compilation of HLSL shaders. Shaders will be introduced in the next lesson.

The DirectX Math library provides SIMD-friendly C++ types and functions for commonly used for graphics related programming [16]. The DirectX Math library will be used in the later tutorials.

The D3D12 extension library (d3dx12.h included on line 32) is not required to work with DirectX 12 but it provides some useful classes that will simplify some of the functions that will be used throughout this tutorial. The d3dx12.h header file is not included as part of the Windows 10 SDK and needs to be downloaded separately from the Microsoft DirectX repository on GitHub (https://github.com/Microsoft/DirectX-Graphics-Samples/tree/master/Libraries/D3DX12)

A few headers from the Standard Template Library (STL) are also included in the demo.

The algorithm header contains math related functions such as std::min and std::max.

The cassert header contains the assert macro.

The chrono header contains time related functions. The chrono::high_resolution_clock is used to perfom timing in between calls to the Update function.

The only header file that is local to the project is the Helpers.h header file.

The Helpers.h header file contains functions and classes that provide helper functionality that may be useful in several source files. Currently, the contents of the Helpers.h header file is very simple.

The Helpers.h header file defines a single function that can be used to check the return value of a DirectX API function. If the function returns an fail code, an exception is thrown. This is useful for debugging the application and simplifies error checking in the main application code.

In the next section, the variables used by the application are defined. Tweak variables and variables that control the application initialization are defined first.

The g_NumFrames constant variable defined on line 44 controls the number of back buffer surfaces for the swap chain. This value must not be less than 2 when using the flip presentation model. Details about the swap chain and flip models are discussed in more detail later.

The g_UseWarp variable controls whether to use a software rasterizer (Windows Advanced Rasterization Platform – WARP) or not. The software rasterizer allows the graphics programmer to access the full set of advanced rendering features that may not be available in the hardware (for example, when running on older GPUs). The WARP device can also be used to verify the results of a rendering technique if the quality of the vendor supplied display driver is in question.

The g_ClientWidth and g_ClientHeight variables control the size of the client area when the window is first created.

The g_IsInitialized boolean variable is set to true only after all of the DirectX 12 objects have been created. This variable is used to prevent certain window messages (such as the window resize message) from being handled until after the device and swap chain have been fully created.

In the next section, the Windows and DirectX specific variables are defined.

The g_hWnd variable stores a handle to the OS window that will be used to display the rendered image.

When switching to a full-screen window state, the previous size of the window needs to be stored so that when switching back to windowed mode, the window dimensions can be restored correctly. The g_WindowRect variable is used to store the previous window dimensions before going to fullscreen mode.

The DirectX 12 device object is stored in the g_Device variable. The command queue is stored in the g_CommandQueue variable.

The IDXGISwapChain4 interface defines the swap chain. The swap chain is responsible for presenting the rendered image to the window. The swap chain will be discussed in more detail later in the tutorial.

The swap chain will be created with a number of back buffer resources. In order to correctly transition the back buffer resources to the correct state, pointers to the back buffer resources will be tracked in the g_BackBuffers array variable. Although the back buffers of the swap chain are actually textures, all buffer and texture resources are referenced using the ID3D12Resource interface in DirectX 12.

GPU commands are first recorded into a ID3D12GraphicsCommandList. Generally a single command list is needed to record GPU commands using a single thread. Since this demo uses the main thread to record all GPU commands, only a single command list is defined. The g_CommandList variable is used to store the pointer to the ID3D12GraphicsCommandList.

The ID3D12CommandAllocator serves as the backing memory for recording the GPU commands into a command list. Unlike the command list, a command allocator cannot be reused unless all of the commands that have been recorded into the command allocator have finished executing on the GPU. Attempting to reset a command allocator before the command queue has finished executing those commands will result in a COMMAND_ALLOCATOR_SYNC error by the debug layer. The g_CommandAllocators array variable is used to store the reference to the command allocators. There must be at least one command allocator per render frame that is “in-flight” (at least one per back buffer of the swap chain).

The back buffer textures of the swap chain are described using a render target view (RTV). The render target view describes the location of the texture resource in GPU memory, the dimensions (width and height) of the texture, as well as the format of the texture. The RTV is used to clear the back buffers of the render target. In a later tutorial, the RTV will be used to render geometry to the screen.

In previous versions of DirectX, RTVs were created one at a time. Since DirectX 12, RTVs are now stored in descriptor heaps. A descriptor heap can be visualized as an array of descriptors (views). A view simply describes a resource that resides in GPU memory.

A view in DirectX 12 is also called a descriptor. Similar to a view, a descriptor describes a resource. Since the swap chain contains multiple back buffer textures, one descriptor is needed to describe each back buffer texture. The g_RTVDescriptorHeap variable is used to store the descriptor heap that contains the render target views for the swap chain back buffers.

The size of a descriptor in a descriptor heap is vendor specific (Intel, NVidia, and AMD may store descriptors differently). In order to correctly offset the index into the descriptor heap, the size of a single element in the descriptor heap needs to be queried during initialization. The size of a single RTV descriptor is stored in the g_RTVDescriptorSize variable defined on line 66.

Depending on the flip model of the swap chain, the index of the current back buffer in the swap chain may not be sequential. The g_CurrentBackBufferIndex variable is used to store the index of the current back buffer of the swap chain.

A few variables that are used to perform correct GPU synchronization are defined.

The g_Fence variable is used to store the fence object described in section Fence above.

The next fence value to signal the command queue next is stored in the g_FenceValue variable.

For each rendered frame that could be “in-flight” on the command queue, the fence value that was used to signal the command queue needs to be tracked to guarantee that any resources that are still being referenced by the command queue are not overwritten. The g_FrameFenceValues array variable is used to keep track of the fence values that were used to signal the command queue for a particular frame.

If the fence object’s completed value has not reached the fence value specified for the frame, then the CPU thread will stall until the fence value is reached. The g_FenceEvent variable is a handle to an OS event object that will be used to receive the notification that the fence has reached a specific value.

A few variables are defined to control the swap chain’s present method.

The g_VSync variable controls whether the swap chain’s present method should wait for the next vertical refresh before presenting the rendered image to the screen. By default, the swap chain’s present method will block until the next vertical refresh of the screen. This will cap the framerate of the application to the refresh rate of the screen. Setting g_VSync variable to false will cause the swap chain to present the rendered image to the screen as fast as possible which will allow the application to render at an unthrottled frame rate but may cause visual artifacts in the form of screen tearing.

Variable refresh rate displays (NVidia’s G-Sync and AMD’s FreeSync) eliminate screen tearing by allowing the graphics application to determine when the vertical refresh should occur.

The g_Fullscreen variable tracks the fullscreen state of the render window.

The source code for the demo has been organized to minimize the number of functions that need to be forward declared. The windows message call back procedure is an exception and requires a forward declaration so that the callback function can be used to register the window class.

In the next section, the various functions used by the demo application are defined.

Parse Command-line Arguments

The ParseCommandLineArguments function allows a few of the globally defined variables to be overridden by supplying command-line arguments when the application is executed.

The table below describes the command-line arguments supported by the application.

Argument	Description
-w, --width	Specify the width (in pixels) of the render window.
-h, --height	Specify the height (in pixels) of the render window.
-warp, --warp	Use the Windows Advanced Rasterization Platform (WARP) for device creation.

Additional command-line arguments (for example, to specify the application start in fullscreen mode) can be handled by extending this function.

Enable the Direct3D 12 Debug Layer

Before doing anything using either the DXGI or the Direct3D API, the debug layer should be enabled in debug builds.

Enabling the debug layer will help in identifying incorrect usage of the DirectX 12 API. The graphics programmer should strive to eliminate any and all errors and warnings that are reported by the debug layer.

Register the Window Class

Before creating an instance of an OS window, the window class corresponding to that window must be registered. The window class will be automatically unregistered when the application terminates.

The RegisterClassEx function takes a pointer to a WNDCLASSEX structure as its only argument.

The WNDCLASSEX structure has the following definition [17]:

Each member has the following definition:

• UINT cbSize: The size, in bytes, of this structure. Set this member to sizeof(WNDCLASSEXW).
• UINT style: The class styles. In this case, the CS_HREDRAW class style specifies that the entire window is redrawn if a movement or size adjustment changes the width of the client area and the CS_VREDRAW class style specifies that the entire window is redrawn if a movement or size adjustment changes the height of the client area.
• WNDPROC lpfnWndProc: A pointer to the windows procedure that will handle window messages for any window created using this window class. In this case we specify the yet undefined WndProc function that was declared earlier.
• int cbClsExtra: The number of extra bytes to allocate following the window-class structure. This parameter is not used here and should be set to 0.
• int cpWndExtra: The number of extra bytes to allocate following the window instance. This parameter is not used here and should be set to 0.
• HINSTANCE hInstance: A handle to the instance that contains the window procedure for the class. This module instance handle is passed to the WinMain function which will be shown later.
• HICON hIcon: A handle to the class icon. This icon will be used to represent a window created with this class in the taskbar and in the top-left corner of the window’s title bar. You can load an icon from a resource file using the LoadIcon function. If this value is NULL (or nullptr) then the default application icon is used.
• HCURSOR hCursor: A handle to the class cursor. This must be a handle to a valid cursor resource. For this demo, we will use the default arrow icon by specifying LoadCursor( nullptr, IDC_ARROW ).
• HBRUSH hbrBackground: A handle to the class background brush. This member can be a handle to the brush to be used for painting the background, or it can be a color value. A color value must be one of the following standard system colors (the value 1 must be added to the chosen color). If a color value is given, you must convert it to one of the following HBRUSH types:
  • COLOR_ACTIVEBORDER
  • COLOR_ACTIVECAPTION
  • COLOR_APPWORKSPACE
  • COLOR_BACKGROUND
  • COLOR_BTNFACE
  • COLOR_BTNSHADOW
  • COLOR_BTNTEXT
  • COLOR_CAPTIONTEXT
  • COLOR_GRAYTEXT
  • COLOR_HIGHLIGHT
  • COLOR_HIGHLIGHTTEXT
  • COLOR_INACTIVEBORDER
  • COLOR_INACTIVECAPTION
  • COLOR_MENU
  • COLOR_MENUTEXT
  • COLOR_SCROLLBAR
  • COLOR_WINDOW
  • COLOR_WINDOWFRAME
  • COLOR_WINDOWTEXT
• LPCWSTR lpszMenuName: Pointer to a null-terminated character string that specifies the resource name of the class menu, as the name appears in the resource file. If this member is NULL, windows belonging to this class have no default menu.
• LPCWSTR lpszClassName: A pointer to a null-terminated const string which is used to uniquely identify this window class. This class name will be used to create the window instance.
• HICON hIconSm: A handle to a small icon that is associated with the window class. If this member is NULL (or nullptr), the system searches the icon resource specified by the hIcon member for an icon of the appropriate size to use as the small icon.

With the window class registered, the OS window instance can be created.

Create Window Instance

The CreateWindow function is used to create an instance of an OS window.

The window will be created in the center of the primary display device. Care must be taken to prevent the window from being created off-screen. Creating a window larger than the viewable area of the display will cause parts of the window to be offscreen. If the title bar and the window frame are offscreen, then it will not be possible to resize the window to fit in the screen.

The GetSystemMetrics function retrieves specific system metric information. In this case, the SM_CXSCREEN and SM_CYSCREEN system metric are used to retrieve the width and height in pixels of the primary display monitor.

In order to calculate the required size of the window rectangle, based on the desired client-rectangle size, the AdjustWindowRect function is used. The WS_OVERLAPPEDWINDOW window style describes a window that can be minimized, and maximized, and has a thick window frame.

On lines 154-155, the dimensions of the adjusted window rectangle are used to compute the width and height of the window that is to be created.

The top-left corner point of the window is computed on lines 158-159 so that the window appears in the center of the screen. The window position should be clamped to \((0,0)\) to prevent the window from being positioned offscreen.

With the window dimensions known, the window instance can be created.

The CreateWindowExW function has the following signature [18]:

And each parameter has the following definition:

• DWORD dwExStyle: The extended window style of the window being created. For a list of possible values,see Extended Window Styles.
• LPCWSTR lpClassName: A null-terminated string or a class atom created by a previous call to the RegisterClass or RegisterClassEx function. The atom must be in the low-order word of lpClassName; the high-order word must be 0. If lpClassName is a string, it specifies the window class name. The class name can be any name registered with RegisterClass or RegisterClassEx, provided that the module that registers the class is also the module that creates the window.
• LPCWSTR lpWindowName: The window name. If the window style specifies a title bar, the window title pointed to by lpWindowName is displayed in the title bar.
• DWORD dwStyle: The style of the window being created. This parameter can be a combination of the window style values.
• int X: The initial horizontal position of the window. For an overlapped or pop-up window, the X parameter is the initial x-coordinate of the window’s upper-left corner, in screen coordinates. If X is set to CW_USEDEFAULT, the system selects the default position for the window’s upper-left corner and ignores the Y parameter.
• int Y: The initial vertical position of the window. For an overlapped or pop-up window, the Y parameter is the initial y-coordinate of the window’s upper-left corner, in screen coordinates. If an overlapped window is created with the WS_VISIBLE style bit set and the X parameter is set to CW_USEDEFAULT, then the Y parameter determines how the window is shown. If the Y parameter is CW_USEDEFAULT, then the window manager calls ShowWindow with the SW_SHOW flag after the window has been created. If the Y parameter is some other value, then the window manager calls ShowWindow with that value as the nCmdShow parameter.
• int nWidth: The width, in device units, of the window. For overlapped windows, nWidth is the window’s width, in screen coordinates, or CW_USEDEFAULT. If nWidth is CW_USEDEFAULT, the system selects a default width and height for the window; the default width extends from the initial x-coordinates to the right edge of the screen; the default height extends from the initial y-coordinate to the top of the icon area.
• int nHeight: The height, in device units, of the window. For overlapped windows, nHeight is the window’s height, in screen coordinates. If the nWidth parameter is set to CW_USEDEFAULT, the system ignores nHeight.
• HWND hWndParent: A handle to the parent or owner window of the window being created. To create a child window or an owned window, supply a valid window handle. This parameter is optional for pop-up windows.
• HMENU hMenu: A handle to a menu, or specifies a child-window identifier, depending on the window style. For an overlapped or pop-up window, hMenu identifies the menu to be used with the window; it can be NULL if the class menu is to be used.
• HINSTANCE hInstance: A handle to the instance of the module to be associated with the window.
• LPVOID lpParam: Pointer to a value to be passed to the window through the CREATESTRUCT structure (lpCreateParams member) pointed to by the lParam param of the WM_CREATE message. This message is sent to the created window by this function before it returns.

The window has been created but it has not yet been shown. The window is shown only after the DirectX 12 device and command queue have been created and initialized.

In the next section, the DXGI API is used to query for DirectX 12 capable GPU adapters.

Query DirectX 12 Adapter

Before creating the DirectX 12 device, a compatible adapter must be present on the user’s computer. The GetAdapter function is used to query for a compatible adapter.

Before querying for available adapters, a DXGI factory must be created. On line 189, the DXGI factor is created. Enabling the DXGI_CREATE_FACTORY_DEBUG flag during factory creation enables errors to be caught during device creation and while querying for the adapters. The DXGI_CREATE_FACTORY_DEBUG flag should not be used in production builds.

In the case that a WARP device should be used, the IDXGIFactory4::EnumWarpAdapter method can be used to directly create the WARP adapter.

The IDXGIFactory4::EnumWarpAdapter method takes a pointer to a IDXGIAdapter1 interface but the GetAdapter function returns a pointer to a IDXGIAdapter4 interface. In order to cast a COM object to the correct type, the ComPtr::As method should be used (as shown on line 198). When not using ComPtr, the QueryInterface method should be used to query for the correct COM object type. For more information, see the reference documentation for QueryInterface.

When not using a WARP adapter, the DXGI Factory is used to query for hardware adapters. The IDXGIFactory1::EnumAdapters1 method is used to enumerate the available GPU adapters in the system. This method returns DXGI_ERROR_NOT_FOUND if the adapter index is greater than or equal to the number of available adapters.

Since only hardware adapters should be considered, WARP adapters that have the DXGI_ADAPTER_FLAG_SOFTWARE flag set, should be ignored.

To verify that the adapter returned from the IDXGIFactory1::EnumAdapters1 method is a compatible DirectX 12 adapter, a (null) device is created using the D3D12CreateDevice function is used. If this function returns S_OK, then the function succeeded and it is a DirectX 12 compatible adapter.

Generally speaking, the GPU with the largest amount of dedicated video memory (that is not shared with the CPU) is a good indicator of GPU performance. If there are more DirectX 12 compatible GPU adapters (for example, the integrated Intel GPU) in the system, then the one with the largest amount of dedicated video memory is favored.

On line 216, the GPU adapter is cast to a IDXGIAdapter4 interface and retured to the caller.

If a valid GPU adapter is found, the actual DirectX 12 device is created.

Create the DirectX 12 Device

After querying for a valid DirectX 12 compatible adapter, the DirectX 12 device is created.

The DirectX 12 device is used to create resources (such as textures and buffers, command lists, command queues, fences, heaps, etc…). The DirectX 12 device is not directly used for issuing draw or dispatch commands. The DirectX 12 device can be considered a memory context that tracks allocations in GPU memory. Destroying the DirectX 12 device will cause all of the resources allocated by the device to become invalid. If the device is destroyed before all of the resources that were created by the device, then the debug layer will issue warnings about those objects that are still being referenced.

You have already seen the D3D12CreateDevice function being used in the GetAdapter funciton described ealier. In this case, the actual device is created and stored in the d3d12Device2 argument.

The D3D12CreateDevice function has the following signature:

And takes the following parameters:

• IUnknown *pAdapter: A pointer to the video adapter to use when creating a device. Pass NULL (or nullptr) to use the default adapter, which is the first adapter that is enumerated by IDXGIFactory1::EnumAdapters.
• D3D_FEATURE_LEVEL MinimumFeatureLevel: The minimum D3D_FEATURE_LEVEL required for successful device creation.
• REFIID riid: The globally unique identifier (GUID) for the device interface. This parameter, and ppDevice, can be addressed with the single macro IID_PPV_ARGS.
• void **ppDevice: A pointer to a memory block that receives a pointer to the device.

As was mentioned previously, the graphics programmer should try to fix any and all errors and warnings generated by the debug layer before releasing the DirectX 12 application to the general public. In order to facilitate diagnosing errors and warnings generated by the debug layer, the DirectX 12 device provides access to the ID3D12InfoQueue interface. The ID3D12InfoQueue interface is used to enable break points based on the severity of the message and the ability to filter certain messages from being generated.

The ID3D12InfoQueue interface is queried from the ID3D12Device interface using the ComPtr::As method described earlier.

The ID3D12InfoQueue::SetBreakOnSeverity method sets a message severity level to break on (while the application is attached to a debugger) when a message with that severity level passes through the storage filter. The D3D12_MESSAGE_SEVERITY_ERROR and the D3D12_MESSAGE_SEVERITY_WARNING messages are generated if an error or warning is generated by the debug layer. The D3D12_MESSAGE_SEVERITY_CORRUPTION message is generated if a memory corruption occurs.

While all DirectX 12 warnings and errors should be resolved before distributing the application, it may not be practical (or feasible) to address all of the possible warnings that can occur. In such a case, some warning messages can be ignored. A storage queue filter can be specified to ignore certain warning messages that are generated by the debug layer. Messages can be ignored by category, severity, or specific message IDs can be ignored.

No messages are ignored based on their category but the code is left in on line 239 for demonstration purposes.

Since D3D12_MESSAGE_SEVERITY_INFO message severity is for information only, info messages are supressed.

The following warning messages are suppressed based on their message ID:

• CLEARRENDERTARGETVIEW_MISMATCHINGCLEARVALUE: This warning occurs when a render target is cleared using a clear color that is not the optimized clear color specified during resource creation. If you want to clear a render target using an arbitrary clear color, you should disable this warning.
• MAP_INVALID_NULLRANGE and UNMAP_INVALID_NULLRANGE: These warnings occur when a frame is captured using the graphics debugger integrated in Visual Studio. Since I think this bug will never be fixed in the debugger, it’s best to just ignore this warning.

On lines 254-260 the info queue filter is defined and the filter is pushed on the info queue using the ID3D12InfoQueue::PushStorageFilter method.

On line 266, the DirectX 12 device is returned to the calling function.

Before creating the swap chain, the command queue must be created first.

Create the Command Queue

The CreateCommandQueue function is used to create the command queue for the application.

The command queue is created using the ID3D12Device::CreateCommandQueue method. This method takes a D3D12_COMMAND_QUEUE_DESC structure as the first argument. The D3D12_COMMAND_QUEUE_DESC structure has the following definition:

The members of the D3D12_COMMAND_QUEUE_DESC structure are:

• D3D12_COMMAND_LIST_TYPE Type: Specifies the type of command queue to create and can be one of the following types:
  • D3D12_COMMAND_LIST_TYPE_DIRECT: The command queue can be used to execute draw, compute, and copy commands. This is the most general type of command queue and will be used in most cases.
  • D3D12_COMMAND_LIST_TYPE_COMPUTE: The command queue can be used to execute compute and copy commands.
  • D3D12_COMMAND_LIST_TYPE_COPY: Command queue can be used to execute copy commands.
• INT Priority: The priority for the command queue. Can be one of the following values:
  • D3D12_COMMAND_QUEUE_PRIORITY_NORMAL: The command queue has normal priority.
  • D3D12_COMMAND_QUEUE_PRIORITY_HIGH: The command queue has high priority.
  • D3D12_COMMAND_QUEUE_PRIORITY_GLOBAL_REALTIME: The command queue has global realtime priority.
• D3D12_COMMAND_QUEUE_FLAGS Flags: Specifies additional flags from the D3D12_COMMAND_QUEUE_FLAGS enumeratrion. Currently, the only additional flag is D3D12_COMMAND_QUEUE_FLAG_DISABLE_GPU_TIMEOUT which indicates that the GPU timeout should be disabled for this command queue. Be careful when using this flag. If you encounter errors with GPU timeouts, you should probably address the error instead of using this flag.
• UINT NodeMask: For single GPU operation, set this to zero. If there are multiple GPU nodes, set a bit to identify the node (the device’s physical adapter) to which the command queue applies. Each bit in the mask corresponds to a single node. Only 1 bit must be set. For more information refer to Multi-Adapter.

Check for Tearing Support

Variable refresh rate displays (NVidia’s G-Sync and AMD’s FreeSync) require tearing to be enabled in the DirectX 12 application to function correctly. This feature is also known as “vsync-off” [19].

Screen tearing occurs when a moving image is presented to the screen out-of-sync with the vertical refresh rate of the screen. An example of screen tearing can be seen in the image below.

To create an application that supports variable refresh rate displays, the DXGI_FEATURE_PRESENT_ALLOW_TEARING feature must be supported and the DXGI_SWAP_CHAIN_FLAG_ALLOW_TEARING must be specified when creating the swap chain. Additionally, the DXGI_PRESENT_ALLOW_TEARING flag must be used when presenting the swap chain with a sync-interval of 0.

Support in in the Windows Display Driver Model (WDDM) for variable refresh rates was added in version 2.1. WDDM 2.1 was added in the Windows 10 Anniversary Update (version 1607) which introduced the DXGI 1.5 API to the Windows 10 SDK. In order to make sure tearing is supported on the user’s computer, it must be queried using the IDXGIFactory5::CheckFeatureSupport method.

The IDXGIFactory5::CheckFeatureSupport method has the following signature:

And takes the following parameters:

• DXGI_FEATURE Feature: Specifies one member of DXGI_FEATURE to query support for. Currently, the following features can be queried:
  • DXGI_FEATURE_PRESENT_ALLOW_TEARING: The display supports tearing, a requirement of variable refresh rate displays.
• void *pFeatureSupportData: Specifies a pointer to a buffer that will be filled with data that describes the feature support.
• UINT FeatureSupportDataSize: The size, in bytes, of pFeatureSupportData.

The next step in initializing DirectX 12 is to create the swap chain.

Create the Swap Chain

The primary purpose of the swap chain is to present the rendered image to the screen. The swap chain stores no less than two buffers that are used to render the scene. The buffer that is currently being rendered to is called the back buffer and the buffer that is currently being presented is called the front buffer. The back buffer is swapped with the front buffer using the IDXGISwapChain::Present method. In previous versions of DirectX, the DXGI presentation model used a bit-block transfer (bitblt) model to present the rendered image to the display. When using a bitblt presentation model, the Direct3D runtime copied the contents of the front buffer to a Desktop Window Manager (DWM) redirection surface. Only after the contents of the front buffer were fully copied to the redirection surface was the image presented to the screen.

Windows 8 and DXGI 1.2 introduced the flip presentation model. Using the flip presentation model, the Direct3D runtime passes the front buffer surface directly to the DWM for presentation to the screen. The flip presentation model provides a performance improvement in both space and speed since the redirection surface is no longer required and the front buffer does not need to be copied before it is presented to the screen.

The image above provides a visual example of the DXGI flip model [20]. DirectX 12 does not support the bitblt presentation model and only supports the flip presentation model. There are two flip effects that can be used when creating the swap chain [21]:

• DXGI_SWAP_EFFECT_FLIP_SEQUENTIAL: Use this flag to specify the flip presentation model and to specify that DXGI persist the contents of the back buffer after you call IDXGISwapChain1::Present1. This flag cannot be used with multisampling.
• DXGI_SWAP_EFFECT_FLIP_DISCARD: Use this flag to specify the flip presentation model and to specify that DXGI discard the contents of the back buffer after you call IDXGISwapChain1::Present1. This flag cannot be used with multisampling and partial presentation.

To achieve maximum frame rates while rendering with vsync-off [19], the DXGI_SWAP_EFFECT_FLIP_DISCARD flip model should be used. The discard means that if the previously presented frame is still in the queue to be presented, then that frame will be discarded and the next frame will be put directly to the front of the presentation queue.

When using the DXGI_SWAP_EFFECT_FLIP_SEQUENTIAL presentation model, the DXGI runtime will place the presented frame at the end of the presentation queue. Using this presentation model may cause presentation lag when there are no more buffers to utilize as the next back buffer (the IDXGISwapChain1::Present1 method will likely block the calling thread until a buffer can be made available).

The CreateSwapChain function is used to create the swap chain.

In the first part of the CreateSwapChain function, the DXGI factory is created. This code is similar to the the GetAdapter function shown earlier and is not described in detail here.

The DXGI_SWAP_CHAIN_DESC1 structure is used to describe how the swap chain is created.

The DXGI_SWAP_CHAIN_DESC1 structure has the following definition [22]:

And each member has the following definition:

• UINT Width: A value that describes the resolution width. If you specify a width of 0 when you call the IDXGIFactory2::CreateSwapChainForHwnd method to create a swap chain, the runtime obtains the width from the output window and assigns this width value to the swap-chain description. You can subsequently call the IDXGISwapChain1::GetDesc1 method to retrieve the assigned width value.
• UINT Height: A value that describes the resolution height. If you specify the height as zero when you call the IDXGIFactory2::CreateSwapChainForHwnd method to create a swap chain, the runtime obtains the height from the output window and assigns this height value to the swap-chain description. You can subsequently call the IDXGISwapChain1::GetDesc1 method to retrieve the assigned height value.
• DXGI_FORMAT Format: A DXGI_FORMAT structure that describes the display format.
• BOOL Stereo: Specifies whether the full-screen display mode or the swap-chain back buffer is stereo. TRUE if stereo; otherwise, FALSE. If you specify stereo, you must also specify a flip-model swap chain.
• DXGI_SAMPLE_DESC SampleDesc: A DXGI_SAMPLE_DESC structure that describes multi-sampling parameters. This member is valid only with bit-block transfer (bitblt) model swap chains. When using flip model swap chain, this member must be specified as {1, 0}.
• DXGI_USAGE BufferUsage: A DXGI_USAGE-typed value that describes the surface usage and CPU access options for the back buffer. The back buffer can be used for shader input (DXGI_USAGE_SHADER_INPUT) or render-target output (DXGI_USAGE_RENDER_TARGET_OUTPUT).
• UINT BufferCount: A value that describes the number of buffers in the swap chain. When you create a full-screen swap chain, you typically include the front buffer in this value. The minimum number of buffers When using the flip presentation model is two.
• DXGI_SCALING Scaling: A DXGI_SCALING-typed value that identifies resize behavior if the size of the back buffer is not equal to the target output. This member can be one of the following values:
  • DXGI_SCALING_STRETCH: Directs DXGI to make the back-buffer contents scale to fit the presentation target size. This is the implicit behavior of DXGI when you call the IDXGIFactory::CreateSwapChain method.
  • DXGI_SCALING_NONE: Directs DXGI to make the back-buffer contents appear without any scaling when the presentation target size is not equal to the back-buffer size. The top edges of the back buffer and presentation target are aligned together. If the WS_EX_LAYOUTRTL style is associated with the HWND handle to the target output window, the right edges of the back buffer and presentation target are aligned together; otherwise, the left edges are aligned together. All target area outside the back buffer is filled with window background color.
    This value specifies that all target areas outside the back buffer of a swap chain are filled with the background color that you specify in a call to IDXGISwapChain1::SetBackgroundColor.
  • DXGI_SCALING_ASPECT_RATIO_STRETCH: Directs DXGI to make the back-buffer contents scale to fit the presentation target size, while preserving the aspect ratio of the back-buffer. If the scaled back-buffer does not fill the presentation area, it will be centered with black borders. This constant is supported on Windows Phone 8 and Windows 10. This constant cannot be used with IDXGIFactory2::CreateSwapChainForHwnd.
• DXGI_SWAP_EFFECT SwapEffect: A DXGI_SWAP_EFFECT-typed value that describes the presentation model that is used by the swap chain and options for handling the contents of the presentation buffer after presenting a surface. Valid values for this member are:
  • DXGI_SWAP_EFFECT_FLIP_SEQUENTIAL: Use this flag to specify the flip presentation model and to specify that DXGI persist the contents of the back buffer after you call IDXGISwapChain1::Present1. This flag cannot be used with multisampling.
  • DXGI_SWAP_EFFECT_FLIP_DISCARD: Use this flag to specify the flip presentation model and to specify that DXGI discard the contents of the back buffer after you call IDXGISwapChain1::Present1. This flag cannot be used with multisampling and partial presentation.
• DXGI_ALPHA_MODE AlphaMode: A DXGI_ALPHA_MODE-typed value that identifies the transparency behavior of the swap-chain back buffer. The following values are supported:
  • DXGI_ALPHA_MODE_UNSPECIFIED: Indicates that the transparency behavior is not specified.
  • DXGI_ALPHA_MODE_PREMULTIPLIED: Indicates that the transparency behavior is premultiplied. Each color is first scaled by the alpha value. The alpha value itself is the same in both straight and premultiplied alpha. Typically, no color channel value is greater than the alpha channel value. If a color channel value in a premultiplied format is greater than the alpha channel, the standard source-over blending math results in an additive blend.
  • DXGI_ALPHA_MODE_STRAIGHT: Indicates that the transparency behavior is not premultiplied. The alpha channel indicates the transparency of the color.
  • DXGI_ALPHA_MODE_IGNORE: Indicates to ignore the transparency behavior.
• UINT Flags: A combination of DXGI_SWAP_CHAIN_FLAG-typed values that are combined by using a bitwise OR operation. The DXGI_SWAP_CHAIN_FLAG_ALLOW_TEARING flag should always be specified if tearing support is available. See Check for Tearing Support for more information on detecting tearing support.

With the swap chain description specified, the swap chain can be created.

The IDXGIFactory2::CreateSwapChainForHwnd method is used to create a swap chain that is associated with a OS window handle. This method has the following signature [23]:

And takes the following arguments:

• IUnknown *pDevice: For Direct3D 12 this is a pointer to a direct command queue (refer to ID3D12CommandQueue). This parameter cannot be NULL.
• HWND hWnd: The HWND handle that is associated with the swap chain that CreateSwapChainForHwnd creates. This parameter cannot be NULL.
• DXGI_SWAP_CHAIN_DESC1 *pDesc: A pointer to a DXGI_SWAP_CHAIN_DESC1 structure for the swap-chain description. This parameter cannot be NULL.
• DXGI_SWAP_CHAIN_FULLSCREEN_DESC *pFullscreenDesc: A pointer to a DXGI_SWAP_CHAIN_FULLSCREEN_DESC structure for the description of a full-screen swap chain. You can optionally set this parameter to create a full-screen swap chain. Set it to NULL to create a windowed swap chain.
• IDXGIOutput *pRestrictToOutput: A pointer to the IDXGIOutput interface for the output to restrict content to. You must also pass the DXGI_PRESENT_RESTRICT_TO_OUTPUT flag in a IDXGISwapChain1::Present1 call to force the content to appear blacked out on any other output. If you want to restrict the content to a different output, you must create a new swap chain. However, you can conditionally restrict content based on the DXGI_PRESENT_RESTRICT_TO_OUTPUT flag.
  Set this parameter to NULL if you don’t want to restrict content to an output target.
• IDXGISwapChain1 **ppSwapChain: A pointer to a variable that receives a pointer to the IDXGISwapChain1 interface for the swap chain that CreateSwapChainForHwnd creates.

Switching to a full screen state will be handled manually using a full-screen borderless window. In order to prevent DXGI from switching to a full screen state automatically when pressing the Alt+Enter key combination on the keyboard, the IDXGIFactory::MakeWindowAssociation method is used specifying the DXGI_MWA_NO_ALT_ENTER flag. This effectively prevents DXGI from responding to the Alt+Enter keyboard sequence.

On line 350, the swap chain is converted to the IDXGISwapChain4 interface type using the ComPtr::As method and returned to the calling function.

To render to the swap chain’s back buffers, a render target view (RTV) needs to be created for each of the swap chain’s back buffers. In the next sections, a descriptor heap is created and the views for each back buffer are recorded into the descriptors of the descriptor heap.

Create a Descriptor Heap

A descriptor heap can be considered an array of resource views. As of DirectX 12, before resource views can be created (such as Render Target Views (RTV), Shader Resource Views (SRV), Unordered Access Views (UAV), or Constant Buffer Views (CBV)), a descriptor heap needs to be created. Certain types of resource views (descriptors) can be created in the same heap. For example, CBV, SRV, and UAV can be stored in the same heap but RTV and Sampler views each require separate descriptor heaps. Descriptor heaps will be discussed in more detail in another lesson which deals with binding textures to the rendering pipeline. For now, a descriptor heap is created to store the render target views for the swap chain buffers.

The CreateDescriptorHeap function described above is used to create a descriptor heap of a specific type. The descriptor heap is created based on the D3D12_DESCRIPTOR_HEAP_DESC structure which has the following definition [24]:

The members of the D3D12_DESCRIPTOR_HEAP_DESC structure are:

• D3D12_DESCRIPTOR_HEAP_TYPE Type: A D3D12_DESCRIPTOR_HEAP_TYPE-typed value that specifies the types of descriptors in the heap. The Type member can have one of the following values:
  • D3D12_DESCRIPTOR_HEAP_TYPE_CBV_SRV_UAV: The descriptor heap for the combination of constant-buffer, shader-resource, and unordered-access views.
  • D3D12_DESCRIPTOR_HEAP_TYPE_SAMPLER: The descriptor heap for the sampler.
  • D3D12_DESCRIPTOR_HEAP_TYPE_RTV: The descriptor heap for the render-target view.
  • D3D12_DESCRIPTOR_HEAP_TYPE_DSV: The descriptor heap for the depth-stencil view.
• UINT NumDescriptors: The number of descriptors in the heap.
• D3D12_DESCRIPTOR_HEAP_FLAGS Flags: A combination of D3D12_DESCRIPTOR_HEAP_FLAGS-typed values that are combined by using a bitwise OR operation. The resulting value specifies options for the heap. Valid flags for the descriptor heap creation are:
  • D3D12_DESCRIPTOR_HEAP_FLAG_NONE: Indicates default usage of a heap.
  • D3D12_DESCRIPTOR_HEAP_FLAG_SHADER_VISIBLE: The flag D3D12_DESCRIPTOR_HEAP_FLAG_SHADER_VISIBLE can optionally be set on a descriptor heap to indicate that it can be bound on a command list for reference by shaders. Descriptor heaps created without this flag allow applications the option to stage descriptors in CPU memory before copying them to a shader visible descriptor heap, as a convenience. But it is also fine for applications to directly create descriptors into shader visible descriptor heaps with no requirement to stage anything on the CPU.
    This flag only applies to CBV, SRV, UAV and samplers. It does not apply to other descriptor heap types since shaders do not directly reference the other types.
• UINT NodeMask: For single-adapter operation, set this to zero. If there are multiple adapter nodes, set a bit to identify the node (one of the device’s physical adapters) to which the descriptor heap applies. Each bit in the mask corresponds to a single node. Only one bit must be set.

The descriptor heap is created on line 364 using the ID3D12Device::CreateDescriptorHeap method.

With the descriptor heap created, the render target views (RTV) for the swap chain’s buffers can be created.

Create the Render Target Views

A render target view (RTV) describes a resource that can be attached to a bind slot of the output merger stage (see Output Merger Stage). The render target view describes the resource that receives the final color computed by the pixel shader stage.

More complex usages of render targets will be discussed in the next lesson. For this lesson, the render target will only be cleared to a specific color.

For each back buffer of the swap chain, a single RTV is used to describe the resource.

The size of a single descriptor in a descriptor heap is vendor specific and is queried on line 372 using the ID3D12Device::GetDescriptorHandleIncrementSize method.

In order to iterate the descriptors in a descriptor heap, a handle to the first descriptor in the heap is retrieved on line 374 using the ID3D12DescriptorHeap::GetCPUDescriptorHandleForHeapStart method. This method returns a D3D12_CPU_DESCRIPTOR_HANDLE structure which is a very simple structure that aliases a pointer to a descriptor within a descriptor heap. The CD3DX12_CPU_DESCRIPTOR_HANDLE structure (from the d3dx12.h header file) extends the simple D3D12_CPU_DESCRIPTOR_HANDLE structure providing more functionality to iterate the descriptor heap.

A pointer to the swap chain’s back buffers is queried on line 379 using the IDXGISwapChain::GetBuffer method.

The ID3D12Device::CreateRenderTargetView method is used to create the RTV. The first parameter to this method is the pointer to the resource that contains the render target texture. The second parameter is a pointer to a D3D12_RENDER_TARGET_VIEW_DESC structure. A NULL description is used to create a default descriptor for the resource. In this case, the resource’s internal description is used to create the RTV. The third parameter to the ID3D12Device::CreateRenderTargetView method is the handle to the descriptor where the view is placed.

A pointer to the buffer is also stored in the g_BackBuffers global variable so that the resource can be transitioned to the correct state as will be shown later. Resource transitions will be discussed in more detail later in this lesson.

On line 385, the descriptor handle is incremented to the next handle in the descriptor heap using the Offset method of the CD3DX12_CPU_DESCRIPTOR_HANDLE structure.

In the next sections, the command allocator and command list is created. Command allocators and command lists are required to issue rendering commands to the GPU.

Create a Command Allocator

A command allocator is the backing memory used by a command list. A command allocator is created using the ID3D12Device::CreateCommandAllocator method and must specify the type of command list the allocator will be used with. The command allocator does not provide any functionality and can only be accessed indirectly through a command list. A command allocator can only be used by a single command list at a time but can be reused after the commands that were recorded into the command list have finished executing on the GPU.

The memory allocated by the command allocator is reclaimed using the ID3D12CommandAllocator::Reset method. A command allocator can only be reset after the commands recorded in the command list have finished executing on the GPU. A GPU fence is used to check if the GPU commands have finished executing on the GPU. Using GPU fences to synchronize GPU commands is shown in the following sections.

The CreateCommandAllocator function is used to create the command allocator for the application. In order to achieve maximum frame-rates for the application, one command allocator per “in-flight” command list should be created. The CreateCommandAllocator function shown here only creates a single command allocator but this function will be used later to create multiple allocators for the demo.

The ID3D12Device::CreateCommandAllocator method is used to create the command allocator. This method has the following signature [25]:

Where:

• D3D12_COMMAND_LIST_TYPE type: A D3D12_COMMAND_LIST_TYPE-typed value that specifies the type of command allocator to create. The type of command allocator can be the type that records either direct command lists or bundles. The command allocator can be one of the following types:
  • D3D12_COMMAND_LIST_TYPE_DIRECT: Specifies a command buffer that the GPU can execute. A direct command list doesn’t inherit any GPU state.
  • D3D12_COMMAND_LIST_TYPE_BUNDLE: Specifies a command buffer that can be executed only directly via a direct command list. A bundle command list inherits all GPU state (except for the currently set pipeline state object and primitive topology).
  • D3D12_COMMAND_LIST_TYPE_COMPUTE: Specifies a command buffer for computing.
  • D3D12_COMMAND_LIST_TYPE_COPY: Specifies a command buffer for copying.
• REFIID riid: The globally unique identifier (GUID) for the command allocator interface (ID3D12CommandAllocator). The REFIID, or GUID, of the interface to the command allocator can be obtained by using the __uuidof macro. For example, __uuidof(ID3D12CommandAllocator) will get the GUID of the interface to a command allocator.
• void **ppCommandAllocator: A pointer to a memory block that receives a pointer to the ID3D12CommandAllocator interface for the command allocator.

The command list is created next.

Create a Command List

A command list is used for recording commands that are executed on the GPU. Unlike previous versions of DirectX, execution of commands recorded into a command list are always deferred. That is, invoking draw or dispatch commands on a command list are not executed until the command list is sent to the command queue.

Unlike the command allocator, the command list can be reused immediately after it has been executed on the command queue. The only restriction is that the command list must be reset first before recording any new commands.

The CreateCommandList function is used to create a command list for the application.

The command list is created on line 402 using the ID3D12Device::CreateCommandList method. This method has the following signature [26]:

Where each parameter has the following definition:

• UINT nodeMask: For single GPU operation, set this to zero. If there are multiple GPU nodes, set a bit to identify the node (the device’s physical adapter) for which to create the command list. Each bit in the mask corresponds to a single node. Only 1 bit must be set.
• D3D12_COMMAND_LIST_TYPE type: A D3D12_COMMAND_LIST_TYPE-typed value that specifies the type of command list to create. The command list can be one of the following types:
  • D3D12_COMMAND_LIST_TYPE_DIRECT: Specifies a command buffer that the GPU can execute. A direct command list doesn’t inherit any GPU state.
  • D3D12_COMMAND_LIST_TYPE_BUNDLE: Specifies a command buffer that can be executed only directly via a direct command list. A bundle command list inherits all GPU state (except for the currently set pipeline state object and primitive topology).
  • D3D12_COMMAND_LIST_TYPE_COMPUTE: Specifies a command buffer for computing.
  • D3D12_COMMAND_LIST_TYPE_COPY: Specifies a command buffer for copying.
• ID3D12CommandAllocator *pCommandAllocator: A pointer to the ID3D12CommandAllocator object that the device creates command lists from.
• ID3D12PipelineState *pInitialState: A pointer to the ID3D12PipelineState object that contains the initial pipeline state for the command list. This is optional and can be NULL. If NULL, the runtime sets a dummy initial pipeline state so that drivers don’t have to deal with undefined state. The overhead for this is low, particularly for a command list, for which the overall cost of recording the command list likely dwarfs the cost of one initial state setting. So there is little cost in not setting the initial pipeline state parameter if it isn’t convenient. Since pipeline state objects are not used in this lesson, the parameter can be NULL. Pipeline state objects will be introduced in the next lessons.
• REFIID riid: The globally unique identifier (GUID) for the command list interface. The REFIID, or GUID, of the interface to the command list can be obtained by using the __uuidof macro. For example, __uuidof(ID3D12CommandList) will get the GUID of the interface to a command list.
• void **ppCommandList: A pointer to a memory block that receives a pointer to the ID3D12CommandList or ID3D12GraphicsCommandList interface for the command list.

Command lists are created in the recording state. For consistency, the first operation that is performed on the command list in the render loop (which will be shown later) is a ID3D12GraphicsCommandList::Reset. Before the command list can be reset, it must first be closed. The command list is closed on line 404 so that it can be reset before recording commands in the render loop.

The next several functions deal with GPU synchronization.

Create a Fence

The ID3D12Fence is an interface for a GPU / CPU synchronization object. Fences can be used to perform synchronization on either the CPU or the GPU.

Internally, a fence stores a single 64-bit unsigned integer value. The fence’s initial value is specified when the fence is created. The fence’s internal value is updated on the CPU using the ID3D12Fence::Signal method and it is updated on the GPU using the ID3D12CommandQueue::Signal method.

To wait for a fence to reach a specific value on the CPU, use the ID3D12Fence::SetEventOnCompletion method followed by a call to the WaitForSingleObject function. To wait for the fence to reach a specific value on the GPU, use the ID3D12CommandQueue::Wait method.

The following table summarizes the methods to use to synchronize with a fence object.

	CPU	GPU
Signal	ID3D12Fence::Signal	ID3D12CommandQueue::Signal
Wait	ID3D12Fence::SetEventOnCompletion, WaitForSingleObject	ID3D12CommandQueue::Wait

Pseudo-code for using a fence object was shown previously in the section titled GPU Synchronization.

As a rule-of-thumb, the fence object should be initialized with a value of zero and the fence value should only be allowed to increase. The fence is considered reached if it is equal to or greater than a specific fence value.

As previously explained when discussing GPU Synchronization, each thread or GPU queue should have at least one fence object and a corresponding fence value. The same fence object should not be signaled from more than one thread or GPU queue but more than one thread or queue can wait on the same fence to be signaled.

The CreateFence function is used to create a fence object for the application.

A ID3D12Fence object is created using the ID3D12Device::CreateFence method. This method has the following signature [27]:

And takes the following arguments:

• UINT64 InitialValue: The initial value for the fence. In most normal use-cases, the initial value of the fence should be 0.
• D3D12_FENCE_FLAGS Flags: A combination of D3D12_FENCE_FLAGS-typed values that are combined by using a bitwise OR operation. The resulting value specifies options for the fence. Valid fence flags are:
  • D3D12_FENCE_FLAG_NONE: No options are specified.
  • D3D12_FENCE_FLAG_SHARED: The fence is shared.
  • D3D12_FENCE_FLAG_SHARED_CROSS_ADAPTER: The fence is shared with another GPU adapter.
  • D3D12_FENCE_FLAG_NON_MONITORED: The fence is of the non-monitored type. Non-monitored fences should only be used when the adapter doesn’t support monitored fences, or when a fence is shared with an adapter that doesn’t support monitored fences.
• REFIID riid: The globally unique identifier (GUID) for the fence interface (ID3D12Fence). The REFIID, or GUID, of the interface to the fence can be obtained by using the __uuidof macro. For example, __uuidof(ID3D12Fence) will get the GUID of the interface to a fence.
• void **ppFence: A pointer to a memory block that receives a pointer to the ID3D12Fence interface that is used to access the fence.

An OS event handle is used to allow the CPU thread to wait until the fence has been signaled with a particular value. In the next section, the OS event handle is created.

Create an Event

If the fence has not yet been signaled with specific value, the CPU thread will need to block any further processing until the fence has been signaled with that value. An OS event handle is used to block the CPU thread until the fence has been signaled. The CreateEventHandle function described next is used to create the OS event.

The OS event handle is created using the CreateEvent function which has the following signature [28]:

And takes the following arguments:

• LPSECURITY_ATTRIBUTES lpEventAttributes: A pointer to a SECURITY_ATTRIBUTES structure. If this parameter is NULL, the handle cannot be inherited by child processes.
• BOOL bManualReset: If this parameter is TRUE, the function creates a manual-reset event object, which requires the use of the ResetEvent function to set the event state to nonsignaled. If this parameter is FALSE, the function creates an auto-reset event object, and system automatically resets the event state to nonsignaled after a single waiting thread has been released.
• BOOL bInitialState: If this parameter is TRUE, the initial state of the event object is signaled; otherwise, it is non-signaled.
• LPCTSTR lpName: The name of the event object. If lpName is NULL, the event object is created without a name.

The OS event is used to cause the CPU thread to stall using the WaitForSingleObject function which will be shown later.

Signal the Fence

The Signal function is used to signal the fence from the GPU. It should be noted that when using the ID3D12CommandQueue::Signal method to signal a fence from the GPU, the fence is not signaled immediatly but is only signaled once the GPU command queue has reached that point during execution. Any commands that have been queued before the signal method was invoked must complete execution before the fence will be signaled.

The fence is signaled after all of the commands that have been queued on the command queue have finished executing. The Signal function returns the fence value that the CPU thread should wait for before reusing any resources that are “in-flight” for that frame on the GPU.

The fence is signaled on the GPU using the ID3D12CommandQueue::Signal method. This method has the following signature [29]:

And takes the following arguments:

• ID3D12Fence *pFence: A pointer to the ID3D12Fence object.
• UINT64 Value: The value to signal the fence with when the GPU queue has finished processing any commands that have been queued prior to the signal.

In the next section, a function to wait until the fence is signaled with a particular value is described.

Wait for Fence Value

It is possible that the CPU thread will need to stall to wait for the GPU queue to finish executing commands that write to resources before being reused. For example, before reusing a swap chain’s back buffer resource, any commands that are using that resource as a render target must be complete before that back buffer resource can be reused. Any resources that are never used as a writeable target (for example material textures) do not need to be double buffered and do not require stalling the CPU thread before being reused as read-only resources in a shader. Writable resource such as render targets do need to be synchronized to protect the resource from being modified by multiple queues at the same time.

The WaitForFenceValue is used to stall the CPU thread if the fence has not yet reached (been signaled with) a specific value. The function will wait for a duration specified by the duration parameter which by default has a duration of about 584 million years. It is advisable to provide the correct fence value to wait on otherwise the end-user will be waiting a long time for the application to continue processing.

The currently completed fence value is queried on line 440. If the fence has not yet reached that value, an event object is registered with the fence and is in turn signaled once the fence has reached the specified value.

It is sometimes useful to wait until all previously executed commands have finished executing before doing something (for example, resizing the swap chain buffers requires any references to the buffers to be released). For this, the Flush function is used to ensure the GPU has finished processing all commands before continuing.

Flush the GPU

The Flush function is used to ensure that any commands previously executed on the GPU have finished executing before the CPU thread is allowed to continue processing. This is useful for ensuring that any back buffer resources being referenced by a command that is currently “in-flight” on the GPU have finished executing before being resized. It is also strongly advisable to flush the GPU command queue before releasing any resources that might be referenced by a command list that is currently “in-flight” on the command queue (for example, before closing the application).

The Flush function is simply a Signal followed by a WaitForFenceValue.

On line 450, the fence is signaled on the GPU. The Signal function returns the fence value to wait for. The WaitForFenceValue function is used to wait for the fence to be signaled with a specified value. The Flush function will block the calling thread until the fence value has been reached. After this function returns, it is safe to release any resources that were referenced by the GPU.

In the next sections, the Update and Render functions are described.

Update

For this lesson, the Update function is extremely simple. Its only purpose is to display the frame-rate each second in the debug output in Visual Studio.

First a few variables are declared and the time between subsequent calls to the Update function is computed using a C++11 high-resolution clock.

The frameCounter variable is used to keep track of the number of times the a frame was rendered to the screen since the last time the frame-rate was printed. The elapsedSeconds variable stores the time in seconds since the last time the frame-rate was printed.

The clock variable is a high_resolution_clock which is used to sample time points (std::chrono::time_point).

The t0 variable is the initial point in time and is initialized to the current time.

Each frame, the frameCounter variable is incremented and the delta time is computed on line 463.

On line 464, t0 is updated with the current time point to prepare it for the next frame.

The deltaTime time_point variable stores the number of nanoseconds since the previous call to the Update function. In order to convert the deltaTime from nanoseconds into seconds, it is multiplied by \(1\times 10^{-9}\).

The frame-rate is printed to the debug output in Visual Studio only once per second. If the total elapsed time exceeds one second, then the frame-rate (in frames-per-second) is computed on line 470 and on line 472, it is printed to the debug output.

In order to compute the frame-rate for the next second, the frameCounter and elapsedSeconds variables are reset to 0.

Although this is a simple update function, it demonstrates how to create a simple game loop. See Game Programming Patterns – Game Loop for more information.

In the next section, the Render function is described.

Render

For this simple application, the Render function consists of two main parts:

1. Clear the back buffer
2. Present the rendered frame

In later lessons, the render loop will become more complicated.

In DirectX 12, it is the responsibility of the graphics programmer to ensure that resources are in the correct state before using them. Resources must be transitioned from one state to another using a resource barrier and inserting that resource barrier into the command list. For example, before you can use the swap chain’s back buffer as a render target, it must be transitioned to the RENDER_TARGET state and before it can be used for presenting the rendered image to the screen, it must be transitioned to the PRESENT state.

There are several types of resource barriers:

• Transition: Transitions a (sub)resource to a particular state before using it. For example, before a texture can be used in a pixel shader, it must be transitioned to the PIXEL_SHADER_RESOURCE state.
• Aliasing: Specifies that a resource is used in a placed or reserved heap when that resource is aliased with another resource in the same heap.
• UAV: Indicates that all UAV accesses to a particular resource have completed before any future UAV access can begin. This is necessary when the UAV is transitioned for:
  • Read > Write: Guarantees that all previous read operations on the UAV have completed before being written to in another shader.
  • Write > Read: Guarantees that all previous write operations on the UAV have completed before being read from in another shader.
  • Write > Write: Avoids race conditions that could be caused by different shaders in a different draw or dispatch trying to write to the same resource (does not avoid race conditions that could be caused in the same draw or dispatch call).
  • A UAV barrier is not needed if the resource is being used as a read-only (Read > Read) resource between draw or dispatches.

For this lesson, only transition resource barriers are used. In a later lesson more complex usages of resource barriers will be shown.

Before any commands can be recorded into the command list, the command allocator and command list needs to be reset to its initial state.

On lines 481-482, pointers to the command allocator and back buffer resource are retrieved according to the current back buffer index.

On lines 484-485 the command allocator and command list are reset. This prepares the command list for recording the next frame.

Usually the first operation that is performed on a render target resource is a clear.

Clear

Before the render target can be cleared, it must be transitioned to the RENDER_TARGET state.

The CD3DX12_RESOURCE_BARRIER structure is a helper struct that allows for easy initializing of the various resource barriers. In this case the CD3DX12_RESOURCE_BARRIER::Transition method is used create a transition resource barrier. By default, this will transition all subresources to the same state.

The resource transition must specify both the before and after states of the (sub)resource. This implies that the before state of the resource must be known. The state of the resource cannot be queried from the resource itself which implies that the application developer must track the last know state of the resource. In a single-threaded application, tracking the last known state of the resource is relatively easy task but if the state of the resource needs to be tracked across multiple parallel threads, then it can get complicated. Methods to track the state of resources will be investigated in another lesson. In this lesson, the before and after states of the resource are known so they are hard-coded in the transition barrier structures.

If there is more than a single resource barrier to insert into the command list, it is recommended to store all barriers in a list and execute them all at the same time before an operation that requires the resource to be in a particular state is executed. In this case, there is only one barrier. Since the next operation requires the resource to be in the RENDER_TARGET state, the resource barrier is inserted directly into the command list on line 493.

Now the back buffer can be cleared.

To clear the back buffer, a CPU descriptor handle to a render target view is stored in the rtv variable. The handle is offset from the beginning of the descriptor heap based on the current back buffer index and the size of the descriptor.

The render target is cleared using the ID3D12GraphicsCommandList::ClearRenderTargetView method which has the following signature [31]:

And each parameter:

• D3D12_CPU_DESCRIPTOR_HANDLE RenderTargetView: Specifies a D3D12_CPU_DESCRIPTOR_HANDLE structure that describes the CPU descriptor handle that represents the render target to be cleared.
• FLOAT ColorRGBA[4]: A 4-component array that represents the color to fill the render target with.
• UINT NumRects: The number of rectangles in the array that the pRects parameter specifies.
• D3D12_RECT *pRects: An array of D3D12_RECT structures for the rectangles in the resource view to clear. If NULL, ClearRenderTargetView clears the entire resource view.

After rendering the scene, the current back buffer is presented to the screen.

Present

The last operation performed during rendering is presenting the rendered image to the screen. Before presenting, the back buffer resource must be transitioned to the PRESENT state.

Resource transitions are explained in the previous sections and aren’t repeated here. After transitioning to the correct state, the command list that contains the resource transition barrier must be executed on the command queue.

The command list is closed on line 509 using the ID3D12GraphicsCommandList::Close method. This method must be called on the command list before being executed on the command queue.

The command list is executed on the command queue using the ID3D12CommandQueue::ExecuteCommandLists method which takes a list of command lists to be executed.

The swap chain’s current back buffer is presented to the screen using the IDXGISwapChain::Present method. This method has the following signature [32]:

Where

• UINT SyncInterval: An integer that specifies how to synchronize presentation of a frame with the vertical blank. Valid values are:
  • 0: Cancel the remaining time on the previously presented frame and discard this frame if a newer frame is queued.
  • 1 through 4: Synchronize presentation for at least \(n\) vertical blanks.
• UINT Flags: An integer value that contains swap-chain presentation options. These options are defined by the DXGI_PRESENT constants.

If tearing is supported, it is recommended to always use the DXGI_PRESENT_ALLOW_TEARING flag when presenting with a sync interval of 0. The requirements for using the DXGI_PRESENT_ALLOW_TEARING flag when presenting are:

• The swap chain must be created with the DXGI_SWAP_CHAIN_FLAG_ALLOW_TEARING flag.
• The sync interval passed into Present (or Present1) must be 0.
• The DXGI_PRESENT_ALLOW_TEARING flag cannot be used in an application that is currently in full screen exclusive mode (set by calling SetFullscreenState(TRUE)). It can only be used in windowed mode. To use this flag in full screen Win32 apps, the application should present to a fullscreen borderless window and disable automatic Alt+Enter fullscreen switching using IDXGIFactory::MakeWindowAssociation.

Immediately after presenting the rendered frame to the screen, a signal is inserted into the queue using the Signal function described earlier. The fence value returned from the Signal function is used to stall the CPU thread until any (writeable – such as render targets) resources are finished being used.

After signaling the command queue, the index of the current back buffer is updated.

When using the DXGI_SWAP_EFFECT_FLIP_DISCARD flip model, the order of back buffer indicies is not guaranteed to be sequential. The IDXGISwapChain3::GetCurrentBackBufferIndex method is used to get the index of the swap chain’s current back buffer.

Before overwriting the contents of the current back buffer with the content of the next frame, the CPU thread is stalled using the WaitForFenceValue function described earlier.

In the next section window resizing and switching to full-screen mode is described.

Resize

A resize event is triggered when the window is created the first time. It is also triggered when switching to full-screen mode or if the user resizes the window by dragging the window border frame while in windowed mode. The Resize function will resize the swap chain buffers if the client area of the window changes.

In order to avoid superfluous resizes, the changes to the width and height of the client area are checked for changes. Any references to the swap chain’s back buffers need to be released before resizing the swap chain. Since there may be a command list that is “in-flight” on the GPU which references the swap chain’s back buffers, the GPU needs to be flushed using the Flush function described earlier.

After flushing the GPU command queue, the local references to the swap chain’s back buffers are released on line 544. The per-frame fence values are also reset to the fence value of the current back buffer index.

On line 549 the current swap chain description is queried so that the same color format and swap chain flags are used to recreate the swap chain buffers on line 550.

Since the index of back buffer may not be the same, it is important to update the current back buffer index as known by the application.

After the swap chain buffers have been resized, the descriptors that refer to those buffers needs to be updated. The RTV descriptors are updated on line 555 using the UpdateRenderTargetViews method described earlier.

In the next section, toggling between fullscreen and windowed state is described.

Fullscreen State

Since the swap chain’s swap effect is using a flip effect, it is not necessary for the window to obtain exclusive ownership of the screen in order to achieve maximum frame rates. Switching the back buffer to a full screen exclusive mode using the IDXGISwapChain::SetFullscreenState method can be cumbersome and has the following drawbacks:

• A DXGI_SWAP_CHAIN_FULLSCREEN_DESC structure is required when creating the swap chain to switch to a full screen state.
• The resolution and refresh rate must match one of the supported modes of the monitor. Providing incorrect resolution or refresh rate settings may cause the screen to go black for the end user.
• Switching to full screen exclusive mode might cause any other monitors in a multi-monitor setup to turn black.
• The mouse cursor is locked to the full screen display.
• Switching to a full screen state will fail if the GPU that is rendering is is not directly connected to the display device. This is common in multi-GPU configurations (for example laptops with an integrated Intel graphics chip and a dedicated GPU).

To solve these issues with full screen exclusive mode, the window will be maximized using a full screen borderless window (FSBW) [33].

When using a full screen borderless window the window style is changed so that the window has no decorations (caption, minimize, maximize, close buttons, and frame). The window is then resized to the full screen dimensions of the nearest display. When using a multi-monitor setup, it is possible that the end user wants the game window to be on a different display other than the primary display. To facilitate this functionality, the window should be made full screen on the display that the application window is overlapping with the most. The nearest monitor relative to the application window can be queried using the MonitorFromWindow function. This function returns a handle to a monitor which can be used to query the monitor info using the GetMonitorInfo function.

The SetFullscreen function is used to switch the window to a full screen borderless window.

Before switching to a full screen state, the window rectangle is saved using the GetWindowRect function so that the window can be restored when switching back to windowed mode.

Next, the window style is changed to a borderless window.

The SetWindowLong function is used to set the borderless window style.

In the next step, the dimensions of the nearest monitor to the application window is queried.

The MonitorFromWindow function is used to retrieve a handle to the monitor that is nearest the window for the application.

The properties for the monitor are queried using the GetMonitorInfo function. The structure returned from the GetMonitorInfo function contains a rectangle structure that describes the full screen rectangle for the monitor.

The SetWindowPos function is used to change the position, size and z-order (make sure it is above all other visible windows) of the window. This function has the following signature [34]:

Where

• HWND hWnd: A handle to the window.
• HWND hWndInsertAfter: A handle to the window to precede the positioned window in the Z order. This parameter must be a window handle or one of the following values:
  • HWND_BOTTOM: Places the window at the bottom of the Z order. If the hWnd parameter identifies a topmost window, the window loses its topmost status and is placed at the bottom of all other windows.
  • HWND_NOTOPMOST: Places the window above all non-topmost windows (that is, behind all topmost windows). This flag has no effect if the window is already a non-topmost window.
  • HWND_TOP: Places the window at the top of the Z order.
  • HWND_TOPMOST: Places the window above all non-topmost windows. The window maintains its topmost position even when it is deactivated.
• int X: The new position of the left side of the window, in client coordinates.
• int Y: The new position of the top of the window, in client coordinates.
• int cx: The new width of the window, in pixels.
• int cy: The new height of the window, in pixels.
• UINT uFlags: The window sizing and positioning flags. In this case, the following values are specified.
  • SWP_FRAMECHANGED: Applies new frame styles set using the SetWindowLong function. Sends a WM_NCCALCSIZE message to the window, even if the window’s size is not being changed. If this flag is not specified, WM_NCCALCSIZE is sent only when the window’s size is being changed.
  • SWP_NOACTIVATE: Does not activate the window. If this flag is not set, the window is activated and moved to the top of either the topmost or non-topmost group (depending on the setting of the hWndInsertAfter parameter).

The ShowWindow function is used on line 592 to show the window in a maximized state.

If the window is being restored to a windowed state the window style is changed back to the WS_OVERLAPPEDWINDOW window style and the size and postion of the window is restored to its windowed size. The ShowWindow function is used again on line 606 to activate and display the window normally.

The only thing left to do is to define how the window reacts to window messages (such as key presses and resize events) and to put it all together with the main application glue.

Window Message Procedure

The window message procedure is the WndProc function described next. The window procedure handles any window messages sent to the application. For this simple demo, the following messages are handled:

• WM_PAINT: Repaint a portion of the application’s window contents.
• WM_SYSKEYDOWN, WM_KEYDOWN, and WM_SYSCHAR: Sent to the window with keybaord focus when a key is pressed on the keyboard.
• WM_SIZE: Sent to the window after its size has changed.

The WM_PAINT message handler is shown first.

In order to prevent the application from handling events before the necessary DirectX 12 objects are created, the g_IsInitialized flag is checked. This flag is set to true in the initialization function after all of the required assets have been loaded. Trying to resize or render the screen before the swap chain, command list and command allocators have been created would be disastrous.

When the WM_PAINT message is sent to the window procedure, the Update and Render functions described earlier are invoked.

This WM_PAINT message handler does not call the BeginPaint and EndPaint as doing so would prevent the WM_PAINT message from being called unless the window is resized, or partially occluded by another window. The WM_PAINT message should be sent to the window as often as possible and it will also be invoked while the window is being resized or moved (instead of blocking until the end user releases the mouse button).

Next a few keyboard keys are handled.

The WM_SYSKEYDOWN message is sent to the window procedure function when the Alt key is held while pressing another key combination (for example, Alt+Enter). The WM_KEYDOWN message is sent when any non-system key is pressed (a key is pressed without Alt being held down).

The demo application handles the following keys:

Key	Action
V	Toggle V-Sync.
Esc	Exit the application.
Alt+Enter, F11	Toggle fullscreen mode.

On line 647 the WM_SYSCHAR message is also being handled but nothing is done with it. The WM_SYSCHAR message is posted to the window when a WM_SYSKEYDOWN message is translated by the TranslateMessage function. If the WM_SYSCHAR message is not handled then the default window procedure will handle it and play an annoying system notification sound when pressing Alt+Enter while the window has keyboard focus.

The WM_SIZE message is handled next.

The client area of the window is queried using the GetClientRect function. The client rectangle is used to compute the width and height to resize the swap chain buffers.

If the user clicks the ✖ in the top-right corner of the window, the WM_DESTROY message is sent to the window. Not responding to this message could cause the application instance to never quit.

Clicking the ✖ in the top-right corner of the window will cause the WM_DESTROY message to be sent to the window procedure. Since the application creates only a single window, the WM_QUIT message is sent using the PostQuitMessage method which will cause the application to terminate. The message loop for the application is shown in the next section.

If another windows message is sent other than one of the messages handled in the window procedure described here or the application is not yet initialized, the message is handled by the default window procedure DefWindowProc.

The final function to be described in this lesson is the glue that puts it all together; the main entry point.

The Main Entry Point

The main entry point for Win32 applications is the wWinMain function. This function acts as the glue for all of the functions previously shown in this lesson. All of the functions described previously are utilized to create the basis of a functioning DirectX 12 application. The function begins by setting some context for the application and reads the command-line arguments.

The SetThreadDpiAwarenessContext function sets the DPI awareness for the current thread. The DPI_AWARENESS_CONTEXT_PER_MONITOR_AWARE_V2 is an improved per-monitor DPI awarenes mode which provides new DPI-related scaling behaviours on a per top-level window basis [35]. Using this DPI awareness mode, the application is able to achieve 100% pixel scaling for the client area of the window while still allowing for DPI scaling for non-client areas (such as the title bar and menus). This means that the swap chain buffers will be resized to fill the total number of screen pixels (true 4K or 8K resolutions) when resizing the client area of the window instead of scaling the client area based on the DPI scaling settings.

For example, if you have a 4K UHD (3840×2160 or 2160p) monitor and you have configured your DPI scaling to 150% then the default behaviour would be to size the client area to 2560×1440. Specifying the DPI awareness of the application before creating the window fixes this issue while still allowing for DPI scaling on non-client areas (for example the title bar of the window will still be scaled according to the DPI settings).

The window class name used to register and create an instance of the window class for the application is specified on line 684 and the command-line arguments are parsed on line 685 using the ParseCommandLineArguments function described earlier.

Before doing anything DirectX related, it is highly advisable to enable the debug layer.

The DirectX debug layer is enabled on line 686 using the EnableDebugLayer function described previously. Attempting to enable the debug layer after the Direct3D 12 device context has been created will cause the device to be released.

The tearing support for the application is queried on line 688 using the CheckTearingSupport function described earlier.

On line 690 the window class is registered with the application instance and a window is created on lin 691 using the CreateWindow function described earlier.

On line 695 the window rectangle is queried to prepare the g_WindowRect variable for toggling the full screen state of the window.

Next the DirectX 12 objects are created.

On line 697 the DXGIAdapter object is created using the GetAdapter function described earlier. The adapter is passed to the CreateDevice function to create the ID3D12Device object.

The direct command queue is created on line 701 and the swap chain is created on line 703.

The g_CurrentBackBufferIndex is initialized on line 706. The first back buffer index will very likely be 0 but to be sure it is queried directly from the swap chain instead of making assumptions about the current back buffer index.

On line 708 the RTV descriptor heap is created using the CreateDescriptorHeap function described earlier and the RTV descriptor increment size is queried from the device on line 709.

On line 711 the render target views are fill into the descriptor heap using the UpdateRenderTargetViews function described earlier.

The command list and command allocators are created next.

Since there needs to be at least as many allocators as in-flight render frames, an allocator is created for the each frame (number of swap chain back buffers). However since a single command list is used to record all rendering commands for this simple demo, only a single command list is required. The allocator is created using the CreateCommandAllocator function described earlier and the command list is created using the CreateCommandList function.

The fence and fence event objects are created next.

The fence object used to perform GPU synchronization is created on line 720 using the CreateFence function and the event handle used to block the CPU until a specific fence value has been reached is created on line 721 using the CreateEventHandle function described earlier.

Everything needed to run the application is now initialized. It is safe to show the window and enter the application’s message loop.

After everything is initialized, the g_IsInitialized flag is set to true and on line 725 the window is shown using the ShowWindow function.

The message loop on lines 728-735 is a standard message loop for a windows application. Messages are dispatched to the window procedure (the WndProc function described earlier) until the WM_QUIT message is posted to the message queue using the PostQuitMessage function (this happens on line 632 of the WndProc function).

Before the application process can terminate, it is important to flush any pending command lists on the GPU.

The Flush function is used on line 738 to ensure that any pending command lists have finished executing before exiting the application. It is important to make sure that any resources that may currently be “in-flight” on the GPU have finished processing before they are released. Since all DirectX 12 objects are held by ComPtr‘s, they will automatically be cleaned up when the application exits but this cleanup should not occur until the GPU is no longer using them.

On line 740 the handle to the fence event object is released using the CloseHandle function.

And finally, the value 0 is returned to indicate that no errors occurred.

If everything is working correctly, you should see a window that is cleared with cornflower blue.

I know it’s not very exciting yet. In the next lesson, we’ll add some geometry to the scene.

Conclusion

In this lesson you learned a little bit about the history of DirectX, the various components of the DirectX API and you learned about the various stages of the rendering pipeline. You also learned how to initialize a DirectX 12 application. You learned how to perform correct synchronization of the GPU command queue that is required to perform double-buffered rendering in DirectX 12. You learned how to register and create and window using the Windows (Win32) API and you also learned how to query for DirectX 12 compatible GPU adapters, create a Direct3D 12 device and how to create a swap chain that is associated with the window. You also learned about descriptor heaps, and how to create a render target view in that heap. Additionally, you learned how to use the command allocators and the command list to clear a render target using a clear color. You also learned how to present the rendered image to the screen taking advantage of variable refresh-rate displays. You also learned how to switch to a full screen state using a full screen borderless window (FSBW) taking into consideration the nearest display relative to the application window. You also learned how to handle a few messages using the windows procedure function and finally the application was put together in the main entry point of the application.

Phew! That was a lot of learning but this is only the tip of the iceberg! In future lessons you will learn how to load vertices and indices into index and vertex buffers, how to write and load shader programs, perform basic lighting equations in a pixel shader, and how to perform HDR rendering! So much more to learn… So stay tuned for the next lessons!

If you enjoyed this lesson (or even if you didn’t) please feel free to leave a comment and let me know how I can improve!

Download the Source

The source code for this lesson is available on GitHub:

https://github.com/jpvanoosten/LearningDirectX12

Tutorial1.zip

References

[1] S. Meyers, Effective C++, 2nd ed. Indianapolis, IN: Addison-Wesley, 1998.

[2] S. Meyers, Effective Modern C++: 42 Specific Ways to Improve Your Use of C++11 and C++14, 1st ed. O’Reilly Media, 2014.

[3] Microsoft, “Learn to Develop with Microsoft Developer Network | MSDN”, Microsoft Developer Network, 2017. [Online]. Available: https://msdn.microsoft.com. [Accessed: 13- Sep- 2017].

[4] E. Gamma, R. Helm, R. Johnson and J. Vlissides, Design Patterns: Elements of Reusable Object-Oriented Software. Pearson Education, 1994.

[5] Boost, “Boost C++ Libraries”, Boost.org, 2017. [Online]. Available: http://www.boost.org/. [Accessed: 14- Sep- 2017].

[6] Wikipedia, “DirectX”, en.wikipedia.org, 2017. [Online]. Available: https://en.wikipedia.org/wiki/DirectX. [Accessed: 31- Oct- 2017].

[7] Wikipedia, “Direct3D”, en.wikipedia.org, 2017. [Online]. Available: https://en.wikipedia.org/wiki/Direct3D. [Accessed: 31- Oct- 2017].

[8] C. Eisler, “DirectX Then and Now (Part 1)”, Craig’s Musings, 2006. [Online]. Available: http://craig.theeislers.com/2006/02/20/directx-then-and-now-part-1/. [Accessed: 01- Nov- 2017].

[9] Microsoft, “Shader Model 1 (Windows)”, MSDN, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/bb509654(v=vs.85).aspx. [Accessed: 01- Nov- 2017].

[10] Microsoft, “Shader Model 4 (Windows)”, MSDN, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/bb509657(v=vs.85).aspx. [Accessed: 01- Nov- 2017].

[11] Microsoft, “HLSL Shader Model 6.0 (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/mt733232(v=vs.85).aspx. [Accessed: 10- Nov- 2017].

[12] Microsoft, “DirectX Graphics and Gaming (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/ee663274(v=vs.85).aspx. [Accessed: 10- Nov- 2017].

[13] Microsoft, “Pipelines and Shaders with Direct3D 12 (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/dn899200(v=vs.85).aspx. [Accessed: 10- Nov- 2017].

[14] Microsoft, “Tessellation Stages (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/ff476340(v=vs.85).aspx. [Accessed: 10- Nov- 2017].

[15] Microsoft, “Shader Stages (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/bb205146(v=vs.85).aspx. [Accessed: 10- Nov- 2017].

[16] Microsoft, “DirectXMath (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/hh437833(v=vs.85).aspx. [Accessed: 20- Nov- 2017].

[17] Microsoft, “WNDCLASSEX structure (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/ms633577(v=vs.85).aspx. [Accessed: 22- Nov- 2017].

[18] Microsoft, “CreateWindowEx function (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/ms632680(v=vs.85).aspx. [Accessed: 24- Nov- 2017].

[19] Microsoft, “Variable refresh rate displays (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/mt742104(v=vs.85).aspx. [Accessed: 24- Nov- 2017].

[20] Microsoft, “DXGI flip model (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/hh706346(v=vs.85).aspx. [Accessed: 27- Nov- 2017].

[21] Microsoft, “DXGI_SWAP_EFFECT enumeration (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/bb173077(v=vs.85).aspx. [Accessed: 27- Nov- 2017].

[22] Microsoft, “DXGI_SWAP_CHAIN_DESC1 structure (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/hh404528(v=vs.85).aspx. [Accessed: 27- Nov- 2017].

[23] Microsoft, “IDXGIFactory2::CreateSwapChainForHwnd method (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/hh404557(v=vs.85).aspx. [Accessed: 27- Nov- 2017].

[24] Microsoft, “D3D12_DESCRIPTOR_HEAP_DESC structure (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/dn770359(v=vs.85).aspx. [Accessed: 28- Nov- 2017].

[25] Microsoft, “ID3D12Device::CreateCommandAllocator method (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/dn788655(v=vs.85).aspx. [Accessed: 29- Nov- 2017].

[26] Microsoft, “ID3D12Device::CreateCommandList method (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/dn788656(v=vs.85).aspx. [Accessed: 29- Nov- 2017].

[27] Microsoft, “ID3D12Device::CreateFence method (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/dn899179(v=vs.85).aspx. [Accessed: 30- Nov- 2017].

[28] Microsoft, “CreateEvent function (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/ms682396(v=vs.85).aspx. [Accessed: 30- Nov- 2017].

[29] Microsoft, “ID3D12CommandQueue::Signal method (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/windows/desktop/dn899171(v=vs.85).aspx. [Accessed: 30- Nov- 2017].

[30] R. Nystrom, Game programming patterns. [Lieu de publication inconnu]: Genever Benning, 2014.

[31] Microsoft, “ID3D12GraphicsCommandList::ClearRenderTargetView method (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/dn903842(v=vs.85).aspx. [Accessed: 08- Dec- 2017].

[32] Microsoft, “IDXGISwapChain::Present method (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/bb174576(v=vs.85).aspx. [Accessed: 08- Dec- 2017].

[33] D. Houlton, “Full-screen DirectX* desktop apps using the Flip Presentation Model | Intel® Software”, Software.intel.com, 2017. [Online]. Available: https://software.intel.com/en-us/blogs/2013/06/03/full-screen-direct3d-games-using-borderless-windowed-mode. [Accessed: 11- Dec- 2017].

[34] Microsoft, “SetWindowPos function (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/en-us/library/ms633545(v=vs.85).aspx. [Accessed: 11- Dec- 2017].

[35] Microsoft, “DPI_AWARENESS_CONTEXT handle (Windows)”, Msdn.microsoft.com, 2017. [Online]. Available: https://msdn.microsoft.com/library/mt791579(v=vs.85).aspx. [Accessed: 11- Dec- 2017].
